Tuning update:
Manually Calibrating the Ω 0hms on the mono amplifier,


Were going for 4 Ω on the Mono
So i need to get 28.3V displaying on the multimeter by adjusting the input sensitivity,
That's a lot of voltage pulsing to the sub right there,

Started off by putting levelling the equaliser to "FLAT"


Then set the speaker level to zero


Followed by the signal source boost level to zero


And finally the audio level to 30


I then disconnected all audio feeding to the 4 channel amplifier


Disconnected the sub and connected the banana plugs to the multimeter so no speakers are connected at all,
Just the mono amp feeding to the multimeter,

I then went to set the "input sensitivity" screw on the Mono amplifier to zero, but it was already at zero level :o


I then started the engine and Inserted the 50Hz Sine-wave CD which was recorded at 0dB




Got back to the boot compartment and turned up the screw until the multimeter was displaying as close as possible to 28.3V AC

I say as close as possible because the tweak is so hyper sensitive its very easy to sneeze and have it displaying 47.2V :lol: took two hands to steady it but after two minutes of tweaking were game on :) 28.28V close enough



With the Mono amplifier now set for life,
Time to finally fit the aluminium cover and badge,



Quick change of tester plugs and change of Test CD,
Going to set the 4 channel now,


The four channel amp has two "input sensitivity" controls aswell as two frequency level controls,
This enables a range of configurations which can put all low bass in rear speakers only and all higher levels in front speakers aswell as leaving all bass to the sub alone etc.

The manual provides scenario examples in the back pages to help.




Just going to set both front and back sensitivity for 4 Ω which is what the speakers are rated at,
This will be a target reading of 17.4V on the amplifier speaker outputs,

Ill do more research and find out the best settings for the frequency filters prior to fitting the cover on this one,

Fronts set at 17.32V


Rear set at 17.34V


Ive removed the sine-wave CD,
Reconnected everything,
Put volume to level 15,
Put in a CD and my neighbour two doors down came out to have a look :lol: thats not the people next door, no the people after that yo!! and his cavity walls are pumped with insulation 5H1t the bed!! :lol:
Volume goes to 40 I've had it at 15 for two minutes and my ear drums are sore to be honest.
And were still only one speaker functioning in the back as ive not yet changed the RCA cable,

In other news,
Ive been to Halfords today,
Saved 2.50 on purchasing a Vibe 8AWG amplifier wiring kit using the forum discount card,
Cost 22.50euro


Obtained the replacement RCA cable from its packaging to replace the defective RCA that's currently feeding the rear speakers,


And ive sold the remainder of the kit on eBay :)


#477793 Mk6 Fiesta Flame 1.4 Build Log (Was Fiesta Mk6 5 Door Custom Sub)

Posted by Lenny on 19 April 2015 - 09:57 AM

Just had a quick read of the reviews for the FK coilovers I was looking at. They're on sale at 108. 120 with p&p. Some reviews say they're fantastic for the price (rrp 210). Others say they're horrendous.. so do I go for adjustable coilovers or 30mm lowering springs for £80 or eibach springs for 120.
I'm not really fussed about comfort.. it's a first car (well.. 1st/2nd) so I've not really driven anything else.. I'm after the stance.. which these coilovers apparently have to offer
I don't fancy a full upgrade. It's either coilovers or lowering springs on the stock shocks. Want a drivable stance at a reasonable price


I have some independent knowledge id like to share with you mate,
Figured id introduce it this way so you don't feel I'm trying to steer you in any way or anything,

When fitting lowering springs,
You will need adjustable rear camber bolts to allow the rear wheels to be set correctly via laser alignment,

That's how lowering is done correctly meaning you get optimum performance aswell as no excessive tyre wear.

When fitting coilovers,
You need a front tower strut adjustable caster kit aswell as the adjustable rear camber kit, this allows adjustment of the front shock positioning to enable correct camber alignment at the lower than 35mm stance.
Via laser alignment,

Either spend it on the adjustable kits or spend it on tyres its going to be spent either way,
Cheapest in the long run is to spend it on camber kits,
Boy racers go for the looks, get featured in magazines then move on to the next car,
They don't keep it long enough to see the results,
If fitting the adjustable kits and laser aligned all will be 100% no problems,

If i was you,
Id go for adjustable coilovers,
Because i personally think; 35mm isn't low enough when your rolling 15" rims that entail a 55mm profile tyre,

Your ride height on 35mm springs would be more like a 50mm height,

If you fit adjustable coilovers you can set the ride height at 25mm for example,
This will give you 35mm stance in respect of the tyres and achieve the stance you want while still coping with speed ramps.

I'm not diminishing those rolling 15" or 16" wheels neither, the unsprung mass of anything bigger on a fiesta would wreck the clutch aswell as sacrifice performance,
They are what it needs,
I'm just saying how you can live with and work with it,

May also be worth checking out powerflex website link: https://www.powerflex.co.uk/

For some new bushes, be a good time to fit them when changing the shocks preventative maintenance.
That's just my two pence mate,
There's always going to be debate on lowering reviews as some people have no patience or care to slow down and expect everything now others understand what there doing and take the time to do it rite,
When you understand you appreciate the differences.
That's not a dig at anyone please no paranoia I'm just explaining the way reviews can be quite divide.

Ok you wont be able to take a speed ramp at 50 but you will be able to take a roundabout :)
Which is more fun?
Again I'm sure you would get 50/50 reviews

#477785 Hassen's Ford Focus 1.6 Tdci Build Thread

Posted by Lenny on 19 April 2015 - 09:08 AM

Starting to plan ahead a bit. I contacted the seller in Germany for the B12 kit and he mentioned that it will take 10-15 days to be delivered.
Just double checking now. Will this fit my car? It does say so in the description but want to be 100% sure.http://www.ebay.co.u...=STRK:MEBIDX:IT
Mechanic quoted me 180-200 to fit it and do the tracking. If all goes well, car should be at the mechanics to fit front discs, pads, steel brake lines, rear anti roll bar, rear camber bolts and b12 suspension kit on the 9th May. I will book it in once all parts are ordered.


Will handle like a different car will all those items fitted,
Don't forget to purchase some eibach adjustable rear camber bolts and have the wheels laser aligned when all fitted,

The existing rear camber bolts are spot welded to the rear shock to maintain there fixed position,
Garage will need to cut these off to release the main hub,

Then fit your eibach adjustable bolts,
Here's a link to the same supplier that i bough mine: http://www.ebay.co.uk/itm/230625566464

That's a good price on fitting aswell,
Ford garage wanted 190 to fit mine then asked for 280 after they had fitted despite me having there initial quote in writing in my hand from the previous week with exactly the same guy, lol so i paid him 192euro at the time and i said "quote paid, plus two euro for yourself to purchase a cowboy hat in the euro shop on your way home today pal, i wont be back"

I then had to have laser tracking alignment to correct camber,
Ford had tried to bill me for this at the time but they don't have tracking equipment in the garage, and clearly it wasn't done when i ended up with rear tyres half worn on the inner side:


Anyways sorry I'm goin too far in to it now lol bottom line rear adjustable bolts mate, and laser tracking,

The B12 kit seems to lower the car evenly and at 30mm front and rear it will be 5mm lower than your existing ride height since yours is currently at the same ride height as mine which is lowered on eibach springs,

It states only diesel models,
This leads me to believe that yes it is the correct kit for your car as petrol springs are too soft for diesel models,
The kit doesn't claim to fit both petrol and diesel so i believe it is the correct kit plus the seller has included an encyclopaedia of specific information,

Good price for shocks and springs together as eibach springs alone as a kit are 190 euro its not that much more for the shocks aswell.

The whiteline rear sway bar also comes with some Polyurethane bushes from Powerflex,
It may be of interest to log on to there website and see what other bushes they stock such as tower strut bushes,

Your B12 kit may not come with those and its a good time to have them changed when your changing the shocks as they sandwich between the shock and the chassis.
Link: https://www.powerflex.co.uk/
Fitting cost would be the same as the part is a rquirement, better to change along with shock in my opinion as it will be more cost effective.

Your existing 17x7 wheels with 55mm profile are a good medium between unsprung mass performance and handling,
