Guide: Fitting Reverse Camera Mk2.5 Focus 2008 - 2011

02 January 2015 - 07:42 AM

Guide: Fitting Reverse Camera Mk2.5 Focus 2008 - 2011


ford-focus-2-640x640_zpstoclah7_edit_141

IMG_20141122_202937_zpsvvk7n3w_edit_1416

Hi all,
Not really much to do in this guide mainly because the chosen reverse camera kit is so good,
Has taken a lot of work out of installing.

So here's the Shopping list short and sweet:

Reverse camera:
http://www.dynamicso...1 focus reverse

If you're living in Ireland and wish to. Purchase this item; sign up to parcel motel and receive it for 3.75 shipping.
See link: http://www.parcelmotel.com/

Here's what's in the box:





Very nicely packaged and presented the kit is top quality and i really cant praise it enough :)

It replaces the existing boot handle while incorporating the reverse camera in to the handle,
This guarantees the camera is most definitely centre aligned on the rear of the vehicle aswell as quite discreet.

Pre-crimped terminals ready for splicing in to the existing boot handle cables:

IMG_20141122_083102_zpsui2ncdt_edit_1416

And here's where it becomes worth the money :)

The loom is separated in two halves by this bespoke connection:


This makes things so much easier to install,
Because you're not trying to fish a bulky yellow RCA plug through the rubber goose neck between boot door and main chassis :)
Its a minute plug instead.

So on the end of the loom is your RCA plug for the camera signal:
This plugs in to the rear of your compatable headunit
And the blue cable:
This is a signal feed, it carries positive power from the reverse bulb to the headunit causing the headunit to automatically display the reverse signal each time you put the car in to reverse:


Open Boot Door,

Remove parcel shelf and store in safe place.

Remove both torx screws in side panel:





Useful to have a plastic bottle or something to store all screws in preventing them from loss :


On the boot door there's two grab handles,
Inside these handles are two torx screws; one in each pocket.



Remove both screws:


Now with one hand holding the metal boot door,
Pull down the plastic panel with your other hand.


Here's what's beneath:


Now remove all six Nuts from iside the panel.
This can be awkward when working over head,
I suggest sitting in the boot on the sill,
With your feet on the ground outside the vehicle,
Bring the boot panel down on to your lap makes it much easier to work with,

Also when removing these nuts;
Count the rotations to removal
This avoids over tightening when refitting the panel.

Here's the nut locations:

Left:
IMG_20150103_124940_zpsdgx9oi1_edit_1420

Right:
IMG_20150103_124929_zpsp6g9hqw_edit_1420

After removing the nuts there are two clips which grip in to the boot,
These are quite brittle if they snap you can seal with a small amount of silicone sealant,
There only there to assist alignment of the panel as the bolts do all the gripping.

When the outer panel is removed you will see a rubber grommet like the one in the image below:

Image121_edit_1420354299837_zpshso2ckcm.

It's possible to disconnect a plug inside the boot panel allowing full removal of the panel,
Allowing it to be brought to a table for working with,

Here's what the loom is like dissected from the panels:

IMG_20140831_120756_zps1bhee2o_edit_1420

The single plug on far side of the rubber grommet is the one that's inside the boot panel.
Unplug it and the whole panel is free to remove:



At this point the standard electronic boot handle should be removed by unplugging it from the loom and squeezing the retaining clips from either side of the unit.

Image178_edit_1420355070173_zpsnbchlx2z.





Cut loom plug from the end of the boot handle loom:


Strip ends ready for crimping on the new terminals:

IMG_20141122_164437_zpswnlmutw_edit_1416

Ensure both cables are passing through the boot panel prior to crimping

Insert one cable inside one of the red crimps and squeeze it tight with top of crimping tool.

Repeat on the second terminal,
It doesn't matter which terminal is crimped to which cable in this case.

Following image is for illustration purpose:

IMG_20141229_163454_zpssuqarzz_edit_1419

Working on this guide across the weekend guys,
I've gotta back fill with images and some text,

I didn't get the required images taken at the time of installation because it was so therapeutic to install.
Ill edit across the weekend.



Green&yellow feed is reverse positive:

Guide: Fitting Dual Camera Dvr System Focus Mk2 & Mk2.5

21 December 2014 - 11:01 AM

Guide: Stealth Dual Camera DVR system Focus Mk2 & Mk2.5

I've post this information in my build thread but figured it would work quite as a guide aswell considering the quality of the kit is exceptional.

Shopping list:
DVR System:
http://www.ebay.co.u...STRK:MEBIDX:IT
TF/Micro SD CaHrd 32Gb:
http://www.ebay.co.u...STRK:MEBIDX:IT
Piggy back fuse adaptor:
http://www.ebay.co.u...STRK:MEBIDX:IT
USB Socket kit:
http://www.ebay.co.u...edirect=mobile
Suction cup disc:
http://www.ebay.co.u...STRK:MEBIDX:IT
Super Steel Glue:
http://www.ebay.co.u...item43d249f06f
PVC Tape:
http://www.ebay.co.u...tem2a05a8fb8f
8.4mm Ring Crimp Terminal:
http://www.ebay.co.uk/itm/180648089396

Where possible the above items have been purchased from the same supplier to save money on shipping,
AutoStar are top supplier of automotive electrical equipment my number one supplier throughout all my guides quality guaranteed.

The USB socket kit I've chosen has two sockets,
So if like me you have a TomTom Satnav,
You may wish to purchase this USB cable to power your Satnav from the USB socket aswell freeing up the 12V socket in the centre console:
http://www.ebay.co.u...STRK:MEBIDX:IT

The goal is to mount the 3.5" DVR unit hidden inside the glovebox mounted on its suction cup arm,
It can be flipped down if required.

It will be powered by the USB socket which is also mounted inside the glovebox and power is provided by the piggy back fuse adaptor pluged in to a 12v ignition feed.

The DVR unit also has its own internal rechargeable battery just the same as a Satnav,
It can be set to wake up and record if movement is detected outside of the vehicle when the car is parked, without draining the car battery,

The system automatically begins to record when power is provided from ignition,

It can also take still photo images on command.

The video quality is 720P HD
The unit records two separate videos in full screen for both front and rear camera.

The cameras themselves are quite discreet and following this installation guide will provide optimum stealth results.

So here's the DVR system and whats in the box:

IMG_20141124_184448_zps7feob90_edit_1416

IMG_20141124_184513_zpsuzjpqug_edit_1416

IMG_20141124_184500_zpsusokctr_edit_1416

IMG_20141124_185119_zpsbhwsroh_edit_1416

IMG_20141124_184545_zpssb2n4n2_edit_1416

IMG_20141124_184601_zpsarhik9u_edit_1416

Rear Camera:

IMG_20141124_184617_zps7vifunk_edit_1416

Front Camera:

IMG_20141124_184631_zpszgjaqch_edit_1416

Standard 12V to USB supply:

IMG_20141124_184652_zpsgkxgnot_edit_1416

IMG_20141229_171223_zpsy4mye4e_edit_1419

Screen mount:

IMG_20141124_184642_zpsmxhbgek_edit_1416

Now to get fitting,

Open glovebox,

Remove several screws

Slide out glove box
Bring to table or work bench.
At this point we need the glue and suction cup disc:

IMG_20141125_174405_zps7koz9bx_edit_1416

IMG_20141125_174348_zpstayermj_edit_1416

Mount the suction cup bracket from the DVR to the suction cup base and trial fit,


As you can see the roof of the glovebox isn't flush smooth,

IMG_20141205_163451_zpsyoqca6a_edit_1417

I first trimmed down the suction cup base in a bid to obtain complete flush contact between base and roof:

IMG_20141205_163508_zps8m11smz_edit_1417

Quick trial fit and still not 100%

IMG_20141205_163520_zpsnapgzkk_edit_1417

IMG_20141205_163525_zpsc4s4tq8_edit_1417

[img]http://i575.photobuc... main chassis.

Using some PVC tape; attach end of loom to a hard length of grass strimmer line or cable makes it easier to fish through the Goose neck.

When through the Goose neck,

Gently remove the rubber seal from around the boot door,

Route cable with attached plastic line;
Out from between roof lining and roof of the car until all is through.

Next remove the parcel shelf for temporary storage,

Remove the two torx screws securing the side panel.

Next using a flat head screwdriver;
Remove plastic grommets in C pillar panels revealing some Philips head screws.

Remove these screws to allow s
Refit parcel shelf
And
Close boot door,

Rear camera now fitted inside 35% tint, not even visible from outside :)


IMG_20141201_130133_zps7kiwoox_edit_1417

Now installing the USB socket kit:


I had initially planned to mount it on the top rear section of the glovebox opposite the vent,

IMG_20141224_131126_zpslm3m0dn_edit_1419

On physical trial fit though; there's not enough space back there to allow it fit,

Best alternative option was the upper right corner of the glovebox.

IMG_20141224_131215_zpskdtjvoo_edit_1419

IMG_20141224_131225_zpssusqwap_edit_1419

I haven't got the required size of hole-saw to drill it,
So I've used the bracket as a template for cutting it out with a dremil;


Quick trial fit inserting it in backwards for trial purposes,
Don't worry about rough edges because there's a lip on the socket covers it from view as you can see in images below;




Now fitting snug,
Time to remove and insert the correct way around.

Prior to putting on the securing plastic ring.



Looking very tidy inside the glovebox :)




Installing USB cable,

I had this 1.5M USB cable that came with my TomTom Satnav back in 2010 so I've chosen to use it for this installation because it has a 90 Degree fitting that works quite well with the design of flip down DVR.

IMG_20141224_133446_zpsnrvkkxp_edit_1419

I didn't like the idea of trailing the USB cable inside the glovebox as it looks untidy and liability of getting caught up in things,

So i cut out a small section in the top of the glovebox allowing the small plug pass through,

IMG_20141224_133511_zpsz3ympw1_edit_1419

When the cable is through;
Plug in the USB to the socket,
Create a comfortable elbow on the cable inside the glovebox.

IMG_20141224_133615_zpsbu8k0qw_edit_1419


Patch inside area of the hole using PVC tape,

Then mix up a small bit of Super Steel to patch up the hole from outside the glovebox,


The PVC tape on the inside will hold the glue while it sets hard filling the gap :)
Tape can be removed after 20 minutes of applying the glue.

I then masked up sections of the usb cable,
Prior to applying some more Super Steel weld,
Then removing tape after 20 minutes,
Bonding the cable to the glovebox nicely.





Looks tidy and wont get caught in anything.
When completed and dry,
Bring glovebox back to the car

Ensure positive and negative feeds are correctly identified and attached to the USB socket:

IMG_20141224_131250_zpswrwtjz6_edit_1419

Earth feed:
With the glovebox still removed; look inside the area to see a bolt securing a crimped ring terminal earth feed:


Remove bolt and cut the earth feed to the desired length followed by crimping on a replacement ring terminal:
Loop ring terminal on to bolt just like a washer and insert bolt back in to place.

IMG_20141229_162443_zpsofdqad6_edit_1419

IMG_20141229_163454_zpssuqarzz_edit_1419

IMG_20141229_163657_zpsedkywp1_edit_1419

IMG_20141229_163717_zpsseft69u_edit_1419

IMG_20141229_163943_zpsptq31nt_edit_1419

Flip down passenger fuse box,

Fish positive feed from socket down to the fuse board area and obtain the piggy back adaptor:


Cut the positive feed to desired length,


Strip terminal and crimp on the piggy back adaptor.

Remove fuse from the USB power supply kit loom and insert it in to top socket of the piggyback adaptor:


IMG_20141224_172840_zpsq8zhbja_edit_1419

With glovebox work now complete,
Route cables from both cameras in through to DVR unit,
Plug in camera feeds following the power feed.


Still folds up hidden out of direct view and obstruction :)

Secure all 7 screws and return all items to glovebox;


Final task now is fitting the piggy back fuse to a switched ignition live feed in the passenger footwell fuse board.

Ive gotta edit this section as i study Haynes manual in search of a switched live fuse location on the board.
Unplug fuse: F100
Insert this fuse in to piggy back adaptor,
Insert piggyback in to original fuse location in slot F100

Ill also insert images of removing panels and insert them among the text.

The DVR unit can then be flipped up and locked,
Now hidden from view and no obstruction to the standard operation of the glovebox.
It records automatically no need to touch it :)

IMG_20141229_170249_zps9wtnngj_edit_1419

Working on this guide across the next few days guys,
I've gotta back fill with images but we will get there by New Years day :)

Thanks for viewing my guide,
See my other guides linked on my Profile page.
