Fordmeet Sept 2014 Leeds

03 August 2014 - 08:48 PM


Sent from my GT-I9505 using Ford OC mobile app

Anyone Fitted Usb In Blank Plug In Focus Mk2.5

27 July 2014 - 03:33 PM

Hi, has anyone fitted a usb in spare blank plug in the centre console next to the heated screen button.
Seen on ebay which a usb & a 3.5mm jackplug. I would like to add this so that i can charge ip from usb & use 3.5mm jackplug for aux in ford radio in my 2010 focus titanium.i know their is a aux in 3.5mm pin in the glovebox.but it means trailing aux cable thru or squash cable in glovebox lid.
Thanks.
This is the switch i mean
Ford FOCUS Custom USB Dash Connection Point Custom MP3 + 3.5mm Jack SILVER

321471950469
Yunii

Sent from my GT-I9505 using Ford OC mobile app

Ouchh! Left With This Sunday Night 12,45Am

24 June 2014 - 06:58 PM

This happened last night some t+×t did this & ran off these were brand new & only fitted on saturday.
Devastated.
even the centre was bent & was found 20 yards down the road its in  unsable condition.
even the centre was hit so hard it was found 20 feet away & bent with broken tabs,this cap is metal not plastic like usually.
Yunii


How To Autodimming Rearview Mirror From Mondeo Mk3

25 May 2014 - 09:13 PM

This was done some years ago.
(Please the colour of wire may differ on other models for sidelights on ,on the healamp switch)

Found this how to that i created on another forum which works on focus mk1/1.5 fiesta mk6 & possibly other models with same baseplate on the windscreen.
this was previously posted on mondeo chat section, now that i know this mod is possible, i decided to to post on here the above will fit the 2002 facelift focus. at the moment i've just put the mirror on the exhisting metal base on the screen,still needs wiring up when time ,it has 3 wires 1 is earth,2green/red wires in which one goes to reverse light(not needed &the other green/red is to go to pin 16 on the light switch connecter block. will post pics up once ffoc website starts running again. just ensure the auto dimming mirror comes from 2003 or earlier as later ones has different base.yuni
below shows directions to which way it comes off by pressing 2 .


on the multiplug of the mirror:
pin1=12v ignition to the headlight light switch.also can usefor submarine light so can take a feed ready for future mod.(green/red)
pin2=earth-black. can go to courtesay light as theirs earth (black)
pin3 12v reverse light(not needed)

please note, the mirror on left with round sticker is standard focus, see base plate has a metal base plate(pic on right)this is usually on the screen ,as this is come from breakers ,they pull the entire thing together, which in that case the plate needs sliding off towards the wider part of black base by pushing down metal clip which has 2 studs stopping it, you need to push down to free the slide at the same time pushing the silver base plate from the oval end.



46c5_11.jpg13012009066.jpg13012009065.jpg14012009067.jpg14012009068.jpg18012009072.jpg
above is the baseplate as you would see when you take the exhisting mirror off, if the same then no problem ( the pic is the same as on the focus 2002.

the base on the right is of a later one (enhanced).

the later mirror with water sensor.this mirror does not have a switch.
to remove the above mirror, remove the trim & water sensor then turn the mirror at the stalk 60 degrees.


please note on the earlier mirror (autodimmer) the wire from mirror to headlining will be visble.(1st pic)

please note in the last 3 pics the wire visible above the mirror leading to the headlining & the 3 wired multiplug in the back of the mirror, the green illumenated light shows when you switch your lights on ,this mirror can be switched off as it has off button.
run the wire across the headlining to the drivers side pillar & behind upto the headlight switch & connect to pin 16 by usingconnecter blocks or solder &insulating tape wrapped,ensure the wire doesnt get trapped in the trim ,i tape it to pillar out of the way.yunii
Sent from my GT-I9505 using Ford OC mobile app

Re Dmb Gel Badges With Ford Logo

12 May 2014 - 08:39 PM

As from June dmb will no longer do these with ford logo anymore so hurry & grab them while you can.
Yunii

Sent from my GT-I9505 using Ford OC mobile app
